Wood Pellet Stove Troubleshooting Guide

Since every pellet stove is different, some of the best advice can be found in your stove manual. Whether you’re burning pellets for the first time in a new stove, firing up your system at the start of a new season, or switching to a new brand of pellets, this quick reference guide for troubleshooting some common burn quality issues should come in handy.

The Problem The Likely Culprit The Solution
Poor burn quality Dirty stove Clean your stove according to your manufacturer’s recommendations, or schedule a professional cleaning.
Blackened glass Burning on ‘low’ Adjust heat setting to medium or medium/high.
Excessive clinkers Airflow leak Clean all vents, check and repair/replace all gaskets, adjust damper or airflow setting.
Trouble igniting Air-to-pellet ratio Adjust air-to-pellet ratio by increasing air flow.
Lazy or small flame Air-to-pellet ratio Adjust air-to-pellet ratio by increasing air flow and/or decreasing feed rate.
Low heat output Air-to-pellet ratio Adjust air-to-pellet ratio by increasing air flow and/or increasing feed rate.
Sparks flying / embers in the ash pot Air-to-pellet ratio Adjust air-to-pellet ratio by decreasing air flow and/or decreasing feed rate.
Whole, charred pellets left in the burn pot Air-to-pellet ratio Adjust air-to-pellet ratio by decreasing air flow and/or decreasing feed rate.
Auger jamming / stove shutting down Long pellets Drop bags on the floor – this can break long pellets into a manageable length.
Excessive ash build up / whole, charred pellets in burn pot Short pellets Reduce feed rate.

As you can see, many burn issues are directly related to your stove’s airflow. If you have reviewed your owner’s manual to make the proper settings adjustments, but you’re still experiencing problems…you might have a leak. Wood pellet stoves operate through a system of air intake and exhaust, and the exhaust fan sucks air out through the burn pot to cause combustion of the pellets. It’s important to inspect your venting setup to see if it’s properly sealed, but it’s more likely the leak is through your door gasket.

It’s simple to test the door seal efficiency with a dollar bill. While holding on to one end of the bill, insert the other side into the door, and shut it. Pull out the dollar while the door is still shut, and note the resistance. You shouldn’t be able to remove the bill without a good amount of resistance. Repeat this method all around your door to check the full effectiveness of your gasket.



Please call 1-800-PELLETS if you have any concerns with the quality of your Woodpellets.com fuel. Learn about our Quality Guarantee, here.

Prepare Your Pellet Stove for Power Outages

Source: Eversource NH Twitter

The tail-end of winter this year has been a stressful and unpredictable one at times – especially for those in the northeast. Due to the increased risk of power outages during fluctuating weather patterns, it’s a good time to remind you about preparing your pellet stove for storms.

First – is your stove plugged directly into the outlet, or do you have a surge protector? Most modern pellet stoves have a circuit board that can be damaged without protection from even small electrical surges caused by power outages. Be sure to check your manual for information on electrical recommendations.

Here are three ways to keep your pellet stove operating during a power outage:

  1. Power Inverter
    • This device converts low voltage from batteries into voltage your pellet stove can operate on. Make sure the inverter is a Pure Sine Wave inverter and is at least 1000w. The batteries must be Deep Cycle ones.
  2. Uninterruptible Power Supply
    • A UPS is an all-in-one option that contains batteries, a charger and what’s required to convert low voltage to mains voltage. These devices are typically only good for an hour or so of time – which can be used to safely shut down your pellet stove, or while getting your generator running.
  3. Generator Backup
    • Of course, a generator is a common solution for reinstating a home’s power during an outage. The type and size that’s right for you should be determined after some solid research.

If the power goes out while your pellet stove is operating, and you don’t have any backup system in place – the pellets won’t immediately stop burning…but the components controlling the heat distribution and circulation will cease. With no operating exhaust fan, your stove can fill with smoke which could leak into your home. You’ll need to carefully unplug everything and (unfortunately) open some windows until you can air out the room.





The 5 Questions Pellet Stove Technicians Answer Most

1. Should I do anything special when I turn off my stove for the summer?

Yes! Follow these steps to get your stove ready for its vacation:

Turn off your stove and unplug it. (You should have a surge protector.) Let it cool completely before you begin the process. Start by cleaning the glass with your heat-safe cleaning solvent and a soft cloth, like you have been doing through the heating season. Do NOT use any cleaning solvent with ammonia in it, because it can damage the glass.

Clean out the entire inside and within the hopper, to the best of your ability. If you have a stove vacuum, this will help make sure everything is removed. (Do NOT use a household vacuum because the fine ash can damage it). Or you can always rely on a trained stove technician to use his or her professional tools.

Read >> The 5 Tools You Need to Clean Your Stove Properly

Do NOT leave any wood pellets inside your stove – burned or unburned. Wood pellets are made of kiln-dried, fine wood fibers which will absorb any moisture. If you have moisture inside your stove, the leftover pellets will absorb it and can cause rust to form through the summer, which can create costly damage later. For this same reason, cleaning out all the ports and passages inside your stove is important for your stove’s health.

If you are unable to safely get inside the inner parts of your stove, and have never done so before, we do not recommend this without professional help. Not only are clean passages a best practice for when your stove is shut down, but also during the burning season as well. Make sure to check your owner’s manual for any suggestions that might be specific to your brand of pellet stove. For an extra precaution, schedule a summer cleaning/inspection by a trained pellet stove professional technician.

Note: Cleancare Professional Cleanings are available through our trusted, certified pellet stove technicians in some regions. Give us a call at 1-800-PELLETS, or enter your zip code on our website to see if Cleancare is available in your area.

2. Do I really need to worry about creosote with my pellet stove?

Your wood burning appliance’s venting system carries out the substances produced when wood burns. As the hot substances flow up into the relatively cooler chimney, condensation occurs, which results in creosote residue sticking to the inner walls of the chimney.

Letting creosote accumulate can cause a house fire – which is (hopefully) common knowledge among wood-burners. Although pellet stoves generate significantly less burn residue due to the clean kiln-dried wood fibers in pellets, it’s still critically important to clean and inspect your stove thoroughly, as you would a firewood-burning system.

Here’s a very helpful guide on how to clean your pellet stove throughout the heating season, and the tools you should have: How to Clean Your Wood Pellet Stove in 20 Minutes

3. Why is my flame so weak?

Woodpellets.comIf your flame is weak, or “lazy”, you’re not experiencing the level of heat you should be getting. If it stays weak for an extended amount of time, your stove will likely just shut down. Causes for a smaller than usual flame are usually a part in need of replacement, incorrect air adjustments, or most common – an uncleaned/neglected pellet stove.

Pellet stoves work off of pressurized air, which is drawn from the exhaust. Pet hair, dander, dust and lint are constantly sucked in. If all the passages within your stove haven’t been cleaned out, or your exhaust hasn’t been cleared of debris – air cannot circulate efficiently. Therefore, your flame will not be strong. Aside from occasional tired parts that need replacing, this is more commonly the answer to why you have a weak flame.

4. Should I be burning hardwood or softwood pellets?

Firewood burners prefer to use hardwood in their wood stove or fireplace, because it provides a longer burn compared to softwood due to wood density differences. However, regardless of the type of wood used to produce wood pellets, the pelletizing process produces pellets with the same density. Due to a higher percentage of resin content in softwood, more heat is produced per pound. Therefore, softwood pellets are typically the most popular among pellet stove owners.

5. Why am I getting so much ash?

Woodpellets.comCheck out the specifications on the wood pellets you’re purchasing, and look for the ash content listed. The higher the percentage, the more ash you’ll get, and the more frequent your cleanings will be. Higher quality pellets will have lower ash percentages, and therefore less maintenance.

On top of research, another great way to choose a fuel is by talking to your fellow pellet-burners to see what they’re using and why. Of course, you won’t know what you like for your home and your budget until you run your own tests. But if you’re buying the cheapest pellets with lower heat and higher ash specifications – you shouldn’t expect the same results as the higher quality options available.



Questions? Need to Place an Order for Premium Wood Pellets? Shop Online or Call 1-800-PELLETS to Speak to a Woodpellets.com Representative!

A Portable Outdoor Heater, Powered by Wood Pellets!

This kickstarter campaign recently launched in order to fund the creation of a portable wood pellet fueled outdoor heater, which is easy to take apart and re-assemble. The inventors claim it provides double the heat of a propane heater, at 1/10th of the cost.

According to their website:

“The Q-Flame heater offers an efficient alternative to standard propane units making Q-Flame the sensible choice for those seeking the latest in outdoor heat. As a manufacturer of wood pellet stoves and patio heaters, QSTOVES INC. is dedicated to designing and developing new heaters and stoves that perform better than industry competitors and better for the environment.”

The Q-Flame may be used for outdoor activities, backyard party heat, or even as a helpful tool when the electricity goes out. It’s inexpensive to operate, uses no electricity, and is environmentally friendly. Could you see yourself using a product like this?

To learn more, or make a purchase, see their kickstarter page here: http://kck.st/2ERM8R5



The Effect of Snow on Wood Pellet Stoves

Pellet Stove Vent BlockageHeavy snow buildup can definitely affect your pellet stove’s venting and your burn experience. Wood pellet stoves operate through a system of air intake and exhaust. If this system is hindered by a blockage (or a gasket leak) proper combustion of the pellets can’t happen. Unlike wood stoves, pellet stove venting can be either horizontal, vertical or both.

One of the ways a pellet stove burn exhaust can be set up is horizontally, straight through the exterior wall. (See Fig. A) The exterior vent allows proper air flow within the stove, and the exhaust to escape. If it’s blocked by dense snow – your stove’s ability to ignite and/or stay burning efficiently could be hindered. If your wood pellets aren’t burning through fully – this blockage could be the reason. (See Fig. B)

A similar kind of venting is through the wall with a vertical rise (Fig. C). Vertical piping raises the exhaust further up the exterior wall. This kind of setup holds less risk of snow blockage. However, strong snow drifts (or very high snow accumulation) can still create blockage.

Pellet stoves can also have exhaust vents exiting through the roof – with some variations (Fig. D). If your roof has heavy snow piled up that hasn’t slid off or been pushed off, the vent could be blocked. Make sure to check for blockage – no matter how your stove is vented.

A whole other way your burn experience can be affected by snow is through delivery obstacles.

Our Woodpellets.com delivery trucks park on the street, and bring your pallets up your driveway with a forklift. Of course, there is nothing you can do about large snowbanks taking up space on the road, but you can make sure your driveway is plowed enough for our 8 foot wide forklift. This will help the driver make a successful delivery – and help you avoid delivery delays.

Please let us know if you have any questions. Call 1-800-PELLETS to speak to an expert!





Wood Pellet FAQS

Over one million homes in the United States use wood pellets as a heating source. Although pellet popularity is continually rising, there are still many frequent questions and misconceptions about heating with wood pellets. Below, we have compiled a list of the most common inquiries we hear from both new and existing pellet users.

Can I Store Wood Pellets Outside?

Wood Pellets Stored OutsideYes – as long as you take the necessary steps to protect them. You must inspect your pellets’ packaging carefully before preparing them for outside storage. To protect your pellets from water and from any birds or squirrels that may try to puncture the plastic, you’ll definitely need to fasten a tarp over your fuel. If your pellets are outside for a while – you’ll need to keep checking on it to make sure there hasn’t been any damage or extensive wear.

If you are a customer, and you find damage that has reached the actual wood pellets, call 1-800-PELLETS right away to speak with a Quality Assurance representative.  All Woodpellets.com Quality Certified fuels are backed by a Quality Guarantee, valid for 30 days after the delivery date.

See >> How to Keep Wood Pellets Safely Stored Outside

Can I Use a Wood Pellet Stove as My Home’s Only Source of Heat?

Depending on the location of the stove and the size/efficiency of your home – yes. Some stoves can easily heat up to 2,500 square feet of space. A common practice is to put pellet stoves in parts of the house to create zone heat, but lightly use a central furnace as a back up. It’s especially common to use oil heating as a backup to pellets, for example, when the price of oil rises significantly.

How Much Does a Pellet Stove Cost?

A typical price for buying and professionally installing a pellet stove is around $2,500 to $3,000. Of course, this number will vary depending on where you live and the kind of stove you choose.

Do Pellet Stoves Require Professional Maintenance?

Most owner’s manuals suggest a comprehensive cleaning by a trained technician at least once a year. Some manuals even suggest a checkup after each ton of pellets is burned. Also, the mechanical and electric components that make up your pellet stove can eventually wear out and need repair or replacement – so a cleaning/check-up by a professional could help prevent a surprise part-malfunction.

Read >> Wood Pellet Stove Best Practices

 How Many Bags of Pellets Should I Buy?

Woodpellets.com Driveway DeliveryThe amount of pellets you can expect to burn through in a heating season depends on the quality of the wood pellets and the efficiency of the stove – among other things. However, one bag of quality pellets will commonly provide a full day of good, steady heat.

The average residential wood pellet customer in the Northeast uses 150-200 bags of wood pellets throughout the entire heating season. There are 50 bags in one ton of pellets, so that’s 3-4 tons.

 Is Heating with Pellets Environmentally Friendly?

The carbon footprint of burning wood pellets can be completely neutral, or close to it. If the forests where the wood pellet raw material has been taken from are sustainably managed, the overall carbon footprint is drastically reduced in comparison with fossil fuel heat. A study by The Alliance for Green Heat and VU University Amsterdam revealed that heating with wood pellets can emit about one tenth the carbon as heating with oil.

Are There Additives in Wood Pellets?

No! Wood pellets are 100% natural. There are absolutely no binders or chemicals added to the wood fiber used to create pellets. Wood naturally contains a substance, lignin, that binds wood pellets in their tightly compacted, mostly uniform shape.

>> See: How Wood Pellets Are Made

Are Softwood Pellets Better than Hardwood Pellets?

Most firewood users prefer to burn hardwood in their wood stove or fireplace, because it provides a longer burn compared to softwood due to wood density differences. However, regardless of the type of wood used to produce wood pellets, the pelletizing process produces pellets with the same density. Softwood pellets are actually most sought after, due to a higher percentage of resin content in softwood, more heat is produced per pound.

For any questions we haven’t answered here – please give us a call at 1-800-PELLETS!



How to Prepare Your Pellet Stove for Fall

When it was time to shut down your stove for the summer, did you take the time to do so properly? Probably the most important part of shutting down for the summer is removing all leftover residue and pellets. If you have moisture inside your stove, the leftover pellets will absorb it. This can cause rust to form, which could lead to costly damage.

If you didn’t shut down properly, or if your stove hasn’t had a thorough cleaning in some time – you should consider scheduling one before the heating season begins. A bonus of having a technician work on your stove clean-up is that he or she is able to check on all the stove parts that might need replacement or adjustment.

Aside from the standard ash removal and general maintenance, your wood pellet stove needs additional care not only for safety and preparedness, but also for efficiency. Pellet stoves work off of pressurized air, which is drawn from the exhaust – so pet hair, dander, dust and lint are constantly sucked in. If all the passages within your stove haven’t been cleaned out, or your exhaust hasn’t been cleared of debris – air cannot properly circulate.

Read >> The 5 Tools You Need to Clean Your Pellet Stove Properly

It’s definitely helpful to check your owner’s manual for more insight on this, and to learn more about your pellet stove overall. It’s packed with model-specific information regarding proper stove maintenance, best practices and warranty information – but it’s often overlooked.

Whether you’re taking care of your pellet stove cleaning yourself, or hiring a professional – here’s what the checklist should include for a thorough cleaning:

  • Check Unit for Visible Defects, Ash, Discoloring
  • Vacuum Inside of Unit
  • Remove Baffles – Clean and Reinstall
  • Clean and Inspect Heat Exchanger
  • Remove Access Doors/Panels – Vacuum and Reinstall
  • Clean and Inspect
    • Heat Exchanger
    • Burn Pot
    • Ignitor
    • Ash Pan
    • Convection Fan
    • Glass
    • Combustion Fan
    • Pressure Switch/Hose
    • Tee and Venting
  • Inspect
    • Gaskets
    • Electrical Wiring
    • Auger Motor(s)*
    • Venting Seals
  • Inspect Hopper for Pellet Quality and Excess Fines
  • Vacuum Back of Stove
  • Check and Lubricate Shaker Grate Cam*

 *May not be applicable on some stove models.

We understand that many pellet stove owners take care of cleaning themselves. However, sometimes things are best left to professionals trained specifically for a service. To see if Cleancare Professional Pellet and Wood Stove Cleanings are available in your area, please call 1-800-PELLETS, or type your zip code in at www.Woodpellets.com.



How to Prepare Your Pellet Stove for the Summer

Woodpellets.com Pellet Stove Best PracticesWhen the little stretches of warm days transition into consistent summer weather – you’re ready to let your pellet stove go on vacation. But, there are extra steps you should consider taking to protect your precious heating investment.

Turn off your stove and unplug it from the surge protector, or unplug the entire thing. Why do you need a surge protector? Most modern pellet stoves have a circuit board that can be damaged without protection from even small electrical surges caused by power outages. Be sure to check your manual for information on electrical recommendations.) Once you’re fully disconnected, make sure it’s completely cooled off before moving forward.

Read more

How Heavy Snow Can Affect Your Wood Pellet Stove

Pellet Stove Vent BlockageThe venting on your wood pellet stove can be installed horizontally, vertically or both. The exterior vent allows for proper air flow within the stove, and for the escape of exhaust. If it’s blocked by dense snow – your stove’s ability to ignite and/or stay burning efficiently could be hindered.

A common exhaust setup is horizontal – straight through the exterior wall (See Fig. A). If your wood pellets aren’t burning through fully – this blockage could be the reason…because the exiting air is an important part of your stove’s operation.  (See Figure B).

A similar kind of venting is through the wall with a vertical rise (See Figure C). Vertical piping raises the exhaust further up the exterior wall. This kind of setup creates less risk of snow blockage. However, there’s a possibility of some blockage by strong snow drifts, or a very large snow accumulation.

Pellet stoves can also have exhaust vents exiting through the roof – with some variations  (See Figure D). If your roof has heavy snow piled up that hasn’t slid off or been pushed off, the vent could be blocked.

Proper air flow is key for efficient pellet stove operation. Make sure to check for blockage – no matter how your stove is vented.

Please let us know if you have any questions or concerns about your pellet burning experience.

Woodpellets.com Quality Certified fuels are backed by a Quality Guarantee, which is valid for a full 30 days after your delivery date.



Call 1-800-PELLETS to Speak to an Expert!





An Informed Wood Pellet Burner is a Successful Wood Pellet Burner

Wood Pellet Colors
If you purchased the pellet stove in your home, you probably did a lot of research by reading reviews, comparing prices, learning about available features, and so on. How much do you look into pellets before you make a purchase? It’s a good idea to check out the brand’s heat and ash specifications before you buy. The higher the ash percentage, the more leftover ash you’ll experience – which correlates to how frequent your cleanings will be. Higher quality pellets have lower ash percentages, which means less maintenance for you. As for the heat output, the higher the BTU/lb number, the hotter the burn of course.

Read more
